Wilier Garda Hybrid Shimano 105 Di2
Couldn't load pickup availability
Regular price
€4.939,15
incl. VAT
Regular price
-21%
€6.250,82
Sale price
€4.939,15
incl. VAT
Smile, pedal, dream
In true Wilier style, we have applied the pleasure of assisted pedaling also to our all-round bike dedicated to all those who love road biking without too many extremes. The comfort-oriented geometries come in five frame sizes: XS, S, M, L, XL.
The result is a cleanly designed e-road bike with fully integrated cable routing that inherits the shapes of the sporty version to the point of deceiving at first glance. Garda Hybrid uses the proven and reliable Mahle X35+ drive unit with a 250 Wh motor housed in the rear hub while the battery is housed in the down tube.
That impossible climb is no longer an obstacle from today; on the contrary, it becomes a real springboard. A new perspective, a new way to look at the world and discover, or rediscover, a new dimension: the pleasure of riding without worries.
The result is a cleanly designed e-road bike with fully integrated cable routing that inherits the shapes of the sporty version to the point of deceiving at first glance. Garda Hybrid uses the proven and reliable Mahle X35+ drive unit with a 250 Wh motor housed in the rear hub while the battery is housed in the down tube.
That impossible climb is no longer an obstacle from today; on the contrary, it becomes a real springboard. A new perspective, a new way to look at the world and discover, or rediscover, a new dimension: the pleasure of riding without worries.
Specifications
Drive system: Mahle X35+, 40Nm
Electrical system: MAHLE EBIKEMOTION X35+
Battery: 250Wh, 36V, ANT+ CONNECTIVITY
Display: iWOC
Frame: GARDA HY - CARBON MONOCOQUE NHU MOD + HIGH IMPACT STRENGHT
Fork: GARDA HY - CARBON MONOCOQUE NHU MOD + HIGH IMPACT STRENGHT
Handlebar: BARRA S
Stem: STEMMA S
Headset: WILIER CUSTOM BEARINGS SUPERSLIM
Groupset: SHIMANO 105 R7150 DI2 2X12
Shift levers: SHIMANO 105 DI2 12S ST-R7170
Brakes: SHIMANO 105 BR-R7170
Rotors: SHIMANO 105 CENTER LOCK SM-RT70 160 MM / 140 MM
Front derailleur: SHIMANO 105 DI2 FD-R7150
Derailleur: SHIMANO 105 DI2 12S RD-R7150
Crankset: SHIMANO 105 FC-R7100 50-34T
Bottom bracket: SHIMANO PRESSFIT BB-RS500-PB
Cassette: SHIMANO 105 12S CS-R7100 11-34T
Chain: SHIMANO CN-M7100 12S
Wheels: WILIER WHEEL NDR 28AC ALU
Tires: VITTORIA ZAFFIRO PRO 4 700X28
Saddle: PROLOGO KAPPA
Seatpost: RITCHEY 2-BOLT ALLOY BBK
Axle: THRU AXLE 12X125 FRONT
Frame weight: 1420 g ± 5%
Fork weight: 400 g ± 5%
*The manufacturer reserves the right to change the information on the website without notice, including specifications, models, colors, and materials.
*Images are for illustrative purposes only and may not correspond to the product description.Size chart
| XS | S | M | L | XL | |
|---|---|---|---|---|---|
| C/C (cm) | 37.5 | 40.5 | 44.5 | 47.5 | 51.5 |
| L (cm) | 50.5 | 52.5 | 54.4 | 56.1 | 57.8 |
| H (cm) | 43 | 46 | 50 | 53 | 57 |
| A (°) | 75 | 74.5 | 74 | 73.5 | 73 |
| L1 (cm) | 40.6 | 40.6 | 40.8 | 41 | 41.1 |
| H1 (cm) | 10.4 | 12.1 | 14.5 | 16.6 | 18.5 |
| A1 (°) | 70.5 | 71 | 71.5 | 72 | 72.5 |
| Reach (mm) | 365 | 376 | 383 | 390 | 395 |
| Stack (mm) | 515 | 532 | 555 | 576 | 595 |
×
![]()
×
![]()
