Merida Scultura 6000 V2

Out of stock
SKU: A62411A04336 Barcode: 4711256483795
Color
Size
€2.821,94 incl. VAT
-24% €3.720,25 €2.821,94 incl. VAT

The latest Shimano 105 Di2 electronic groupset, combined with high-quality components from FSA, Continental, and MERIDA, all mounted on the award-winning SCULTURA CF3 frame, make the 6000 one of the most aerodynamic and comfortable classic high-end road bikes in its range.

Are you looking for a lightweight carbon road bike with a super precise electronic groupset, a long list of aerodynamic upgrades, perfect cable integration, frame compliance at the top of its class, ample tire clearance, and high-quality components? Do you race or stay at the front of the pack in fast club races, or do you enjoy rolling profiles? The SCULTURA 6000 equipped with Shimano 105 Di2 could be your perfect bike. Our award-winning SCULTURA is synonymous with "simplified race compliance" and offers exactly that, whatever challenge you throw at it.

Main features

  • Lightweight CF3 carbon frame (approx. 997 g - in size M) with race-proven (identical to REACTO) geometry
  • Shimano 105 Di2 electronic 12-speed groupset
  • FSA SMR ACR two-piece cockpit
  • MERIDA EXPERT SL handlebar
  • DISC COOLER technology
  • MERIDA EXPERT CC carbon seat post

Specifications

FRAME SCULTURA CF3 V
  • material: carbon
  • 700x30C max. wheel size
  • 100x12/ 142x12 mm axle standard
  • Pressfit 86.5
COLOR TEAL/PEARL (TEAM)
FRAME SIZE 3XS, XXS, XS, S, M, L, XL
FORK SCULTURA CF3 disc
  • material: carbon
  • 700x30C max. wheel size
BRAKES Shimano 105
  • Hydraulic disc
DISCS Shimano RT64
  • 160 mm
STEERING SET FSA ACR
HANDLEBAR MERIDA EXPERT SLII
  • material: aluminium
  • 380 mm(XXS) , 400 mm (XS) , 420 mm (S-M-L) , 440 mm (XL)
HANDLEBAR STEM FSA SMR ACR
  • material: aluminium
  • -6° stem angle
  • 90 mm-XXS/XS, 100 mm-S, 110 mm-M, 120 mm-L/XL
GRIPS MERIDA ROAD Expert
FRONT DERAILLEUR Shimano 105 Di2
DERAILLEUR Shimano 105 Di2
CONTROLS Shimano 105 disc Di2
CRANKSET Shimano 105
  • FCR7100, 50-34 teeth
  • 165 mm-XXS, 170 mm-XS, 172.5 mm-S/M, 175 mm-L/XL
SEATPOST MERIDA EXPERT CC
  • 27.2 mm diameter
  • 15 mm setback
  • Carbon
SEATPOST CLAMP MERIDA EXPERT
SADDLE MERIDA EXPERT SL
  • V-mount
  • incl. MERIDA minitool
CHAIN Shimano CN-M6100-12
CASSETTE Shimano CS-R7100
  • 11-34 teeth
  • 12 speed
BOTTOM BRACKET SET Shimano SM-BB71-41B
  • Pressfit 86.5 mm
RIMS MERIDA EXPERT SL
  • 17 mm inner width
  • 22 mm height
  • material: aluminium
  • Tubeless ready (tubeless tape and valves not included)
HUBS VP CLK170F / VP CLK270R
  • 100x12 mm width front hub
  • 28 spoke holes
  • Centerlock
  • 142x12 mm width rear hub
  • 28 spoke holes
  • Centerlock
AXLES MERIDA EXPERT SL
  • including removable lever
  • 6/4 mm allen key
SPOKES Double Butted Black stainless
TIRES Maxxis Highroad
  • 700x28C
  • fold *tubeless ready
MAXIMUM ALLOWED WEIGHT 120 kg
  • Total weight of bike, rider and luggage

*The manufacturer reserves the right to change website information without notice, including specifications, models, colors, and materials.

*Images are for illustrative purposes only and may not correspond to the product description.

Geometry

Frame geometry image

FRAME SIZE 3XS XXS XS S M L XL
TIRE SIZE 28" 28" 28" 28" 28" 28" 28"
ST SEATPOST MM. 400 435 458 481 501 521 550
TT TOP TUBE MM. 505 520 535 545 560 575 590
CS REAR CHAINSTAY MM 408 408 408 408 408 408 408
HTA HEAD TUBE ANGLE DEGREES 70.5 70.5 72 72.5 73.5 73.5 74
STA SEAT TUBE ANGLE DEGREES 75.5 74.5 74 74 73.5 73 73
BD BOTTOM BRACKET DROP MM. 70 70 70 66 66 66 66
HT HEAD TUBE HEIGHT MM. 100 105 112 128 140 155 176
FI FORK LENGTH MM. 385 385 385 385 385 385 385
R REACHS MM 373 377 383 390 395 400 409
S STACKS MM 512 517 529 542 557 571 593
WB WHEELBASE MM 979 985 982 989 990 1000 1010
SH STAND OVER HEIGHT MM 700 721 745 765 782 800 823
